Working size (mm): 4050*1450*2050*2050
Weight (kg) 3000
Width of the conveyer belt (mm) 400
Dimensions in transport position (mm): 2750*1450*2050
Total external width of the protective casing (mm): 1250
Catre size (mm): 300*86*52.5
Input hole size (mm): 250*400
Maximum raw material size (mm): 230*380
Bunker volume (m3): 0.4
Racking height (mm): 950-1000
Recycled material range (mm): φ20-60
Mpa compression strength 240
Speed of movement (km/h): 0-4
Production capacity (t/h tons/hour): 5-10 t/h
Equipment management mode: Manual, hydraulic
Type of drive Hydraulic, tracked
Engine drive model FTM03C
Specifications of hydraulic pump: A10VSO28
Type of conveyor ribbon: Hydraulic
Conveyor lifting method: Hydraulic cylinder
Engine Laidong 385 (Euro V)
Maximum output power output 18.5 kW/2350 um per min
Fuel tank capacity/l 50 l
Volume of oil / l 4 l
Hydraulic oil tank/l 50 l

Free shipping anywhere in Europe.
